Abrasive Vises for Sectioning

Abrasive Vising

Vising for Abrasive Saws and Cutters

Buehler offers a wide range of abrasive vises in small to large sizes. Each vise is designed to address specific requirements, ensuring that you can find the right solution to clamp your sample. Whether you prioritize speed, capacity for large parts, or flexibility to accommodate irregular shapes, we have the vise that perfectly meets your needs.

Abrasive Vising options

  • 2-Piece Quick Sliding Vise — Place your samples directly on the table, maximizing cut capacity under the blade. Effortlessly adjust the sliding jaw for easy loading and unloading and to accommodate different sample sizes and shapes without the need to relocate your vise. Enhance versatility by utilizing the close-gap feature for exceptionally controlled and precise cuts.
  • 2-piece Sliding Vise – Place your samples directly on the table, maximizing the cut capacity under the blade. Easily adjust the front and back blocks to create more space for larger parts or to accommodate irregularly shaped samples. Available in medium and large sizes.
  • MetKlamp VIII and VIIIS – Quickly clamp your samples and ensure parallel cuts using this single piece vise. The VIIIS model is ideal for smaller machines like the AbrasiMet M, while the standard version is ideal for medium-sized machines/samples.
  • Speed Clamping Vise – Clamp samples of any shape with its versatile, reversible jaw plate, featuring sides for cylindrical and irregularly shaped parts. Similar to the MetKlamp VIII, this vise enables quick clamping and ensures parallel cuts. Available in medium and large sizes.
  • Fastener Vise – A specially designed vise accessory for holding small components and coupons. It can be effectively combined with any of the Sliding, MetKlamp, or Speed vises.
  • Vertical Clamping Kit and Riser Blocks – These vises and the best choice for irregularly shaped samples, featuring flexibility to change clamping heads for various geometries and flexibility to place at any point along the T-slots, in any orientation, to achieve the perfect clamp. Available in small and large sizes. Combine with small or large riser blocks to increase the clamping height for larger parts.
  • Vee Block – A valuable addition to vertical clamps, the Vee block is designed to elevate larger parts above the vise table. Use Adjustable Vee Blocks to further lift the Vee blocks.
  • Horizontal Clamp – Designed to enable vertical vises to clamp against a vertical surface instead of the vise table for specialty applications.
  • Chain Clamping Kit – The perfect solution for clamping very large and/or irregularly shaped samples.

Ordering

Abrasive Vising
Single Piece Sliding Vises
Part Number Name Side Description
10-3544 Speed Clamping Vise Medium Left Max Opening: 2.75" [70mm]
Clamping Plate: 3.2" x 1.4" [80 x 35mm]
T-Nuts: 12mm or 14mm
10-3545 Speed Clamping Vise Medium Right Max Opening: 2.75" [70mm]
Clamping Plate: 3.2" x 1.4" [80 x 35mm]
T-Nuts: 12mm or 14mm
10-3546 Speed Clamping Vise Large Left Max Opening: 7.3" [185mm]
Clamping Plate: 3.1" x 3.5" [78 x 89mm]
T-Nuts: 12mm or 14mm
10-3547 Speed Clamping Vise Large Right Max Opening: 7.3" [185mm]
Clamping Plate: 3.1" x 3.5" [78 x 89mm]
T-Nuts: 12mm or 14mm
95-C1821S MetKlamp VIII S Left Max Opening: 2.08" [53mm]
Clamping Plate: 1.75" x 2.25" [45 x 58mm]
T-Nuts: 12mm
95-C1822S MetKlamp VIII S Right Max Opening: 2.08" [53mm]
Clamping Plate: 1.75" x 2.25" [45 x 58mm]
T-Nuts: 12mm
95-C1821 MetKlamp VIII Left Max Opening: 3.125" [80mm]
Clamping Plate: 1.75" x 2.25" [45 x 58mm]
T-Nuts: 12mm
95-C1822 MetKlamp VIII Right Max Opening: 3.125" [80mm]
Clamping Plate: 1.75" x 2.25" [45 x 58mm]
T-Nuts: 12mm
Two Piece Vises
Part Number Name Side Description
10-3580 Medium Quick Sliding Left Clamping Plate: 2.6” x 2.1” [66 x 55mm]
Stroke Length: 2.5” [63mm]
T-nuts: 12mm
10-3581 Medium Quick Sliding Right Clamping Plate: 2.6” x 2.1” [66 x 55mm]
Stroke Length: 2.5” [63mm]
T-nuts: 12mm
10-3540 Medium Sliding Left Clamping Plate: 2.36" x 3" [60 x 76mm]
T-Nuts: 12mm
10-3541 Medium Sliding Right Clamping Plate: 2.36" x 3" [60 x 76mm]
T-Nuts: 12mm
10-3542 Large Sliding Left Clamping Plate: 2.95" x 4.23" [74 x 107mm]
T-Nuts: 12mm
10-3543 Large Sliding Right Clamping Plate: 2.95" x 4.23" [74 x 107mm]
T-Nuts: 12mm
Specialty Vises
Part Number Name Description
46-0030 Chain Clamping Kit Application: For clamping very large or irregularly shaped samples
95-C1702 Fastener Vise Application: For longitudinal sectioning of fasteners. Must be held with either Single Piece (recommended) or Two Piece Left Hand Vising.
Max Opening: 1.6" [40.6mm]
Vertical Clamping Vises
Part Number Name Size Description
10-3531 Vertical Clamping Kit Small Clamping Height: 2.3" [58mm]
Reach: 2.1" [54mm]
T-Nuts: 12mm
10-3523 Vertical Clamping Kit Large Clamping Height: 4" [102mm]
Reach: 2.4" [61mm] + 3.5" [90mm] with extension (included)
T-Nuts: 12mm and 14mm
10-3532 Riser Blocks Small 2.4" [60mm]
10-3528 Riser Blocks Large 2.9" [74mm]
10-3527 Vee Block Clamp Kit   T-Nuts: 12mm and 14mm
10-3526 Horizontal Clamp   T-Nuts: 12mm and 14mm
10-3525 Adjustable Vee Blocks   T-Nuts: 12mm and 14mm
