AbrasiMatic^® 300 Automatic and Manual Abrasive Cutter

AbrasiMatic 300

Automatic and Manual Abrasive Sectioning Machine

The AbrasiMatic 300 automatic and manual abrasive cutter is a 12″ [305mm] benchtop cutter built for demanding workloads. This saw prioritizes flexibility in cutting and setup, allowing users to section a wide variety of sample materials, sizes and geometries. Combine with Buehler’s abrassive wheels for a complete sectioning solution providing optimal sample surface quality and reduced processing time.

AbrasiMatic 300 benefits

Cutting Options

Automatic Y-feed cutting
Manual Z (chop) cutting
Optional manual X serial cutting
Pulse cutting

Fast and Intuitive

Low effort Z axis lever
Easy to control X and Y axes handles for manual cutting
Easy to use touchscreen
Hood lifts up and back to open the chamber for setup
Catch basket for easy part retrieval
Easy to move lights and coolant nozzles

Reliable

Tried and tested machine with over 10 years on the market
Filtering recirculation system to provide clean coolant intake

Ordering

AbrasiMatic 300 - Ordering
Y and Z axis cutting only
Part Number	Voltage	Request a Quote
10-2190-260	200-240VAC, 60Hz	Request a Quote
10-2190-460	440-480VAC, 60Hz	Request a Quote
10-2190-400	380-400VAC, 50Hz	Request a Quote
Additional X Axis cutting
10-2193-260	200-240VAC, 60Hz	Request a Quote
10-2193-460	440-480VAC, 60Hz	Request a Quote
10-2193-400	380-400VAC, 50Hz	Request a Quote

Specifications

AbrasiMatic 300
Voltage/Frequency/Phase	230VAC, 60Hz; 460VAC, 60Hz; 220VAC, 50Hz; 380VAC, 50Hz / 3 phase
Power Consumption	4.0kW
Maximum Current	15.7amps @ 220/230VAC; 7.9amps @ 460VAC; 9.1amps @ 380VAC
Motor Power	5Hp [3.7kW]
Lighting	Two LED Goosenecks
Recirculation Tank Capacity	22gal [83ℓ]
Hose Fitting Sizes	Intake: 1in [25mm]; Discharge: 2in [50mm]
Sound Rating	78dBA – no load
Fume Extractor Size	3in [75mm] cut-out diameter
Control Panel	7in [175mm] diagonal; 320×240 pixels; 256 color screen, backlight NEMA4 [IP 65] water resistant
T-slot table dimensions	14.375 W x 10in D [365 x 254mm]; 12mm wide t-slots
Travel movement Z-Axis:	5.75in [150mm]; Y-Axis: 10.25in [260mm]; X-Axis: 2.75in [70mm]
Auto Y-Axis Feed Rate	0.7-5in/min [0.3-2mm/sec]
Window Size	14 W x 12in H [355 x 300mm]
Abrasive Wheel Diameter & Arbor	Maximum 12in [305mm] & 1.25in [32mm]
Wheel Speed	2600rpm @ 50/60Hz; 8200 surface ft/min [2700 surface m/min]
Maximum Cut Diameter	4.375in [110mm]
Cutting Wheel Torque	121 in/lb [14Nm]
Cutting Chamber	36 W x 22 D x 8in H [914 x 558 x 203mm]
Compliance	CE
