IsoMet® Low Speed Precision Cutter

IsoMet Low Speed

Gravity-fed Precision Sectioning Machine

The IsoMet Low Speed precision cutter is a compact gravity-fed precision saw, 5in [127mm] tabletop machine that delivers the gentlest cut for your sample. Its precision micrometer and user-friendly controls give total control to the user. Pair with Buehler’s diamond / CBN blades and IsoCut coolant for a comprehensive solution with the highest level of quality.

IsoMet Low Speed Benefits

Exceptional Precision and Quality
  • Gravity-fed arm minimizes sample stress ensuring a delicate cut
  • Precision micrometer guarantees accurate sample width
  • Specialized sample chucks for the smallest and most delicate samples
Easy to Use
  • Easily adjustable cutting arm allows users to change vises quickly
  • Adjustable motor speed up to 300rpm for various applications
  • Removable catch tray for easy retrieval of cut sample

Ordering

IsoMet Low Speed - Ordering
Part Number Voltage Units Request a Quote
11-1280-160 115VAC, 50/60Hz Inches Request a Quote
11-1280-170 115VAC, 50/60Hz Millimeters Request a Quote
11-1280-250 230VAC, 50/60Hz Millimeters Request a Quote

Specifications

IsoMet Low Speed
Frequency universal
Voltage 115, 220
Phase 1
Cutting Capacity 1.50[in], 38.00[mm]
Wheel Diameter 5.00[in]
Controls Push Button
Cut Action Gravity Fed Chop
Programmability No
Serial Capabilities No
Wheel Diameter 127[mm]
RPM @60 Hz: 300
Consumables and Accessories
Blades for Precision Saws and Cutters

Vising for Precision Saws and Cutters

Coolants for Sectioning Machines

Flanges for Precision Machines

Related Products
7in [178mm]
Gravity-fed Precision Saw
8in [203mm]
Automatic Precision Saw
8in [203mm]
Thin Section Saw/Cup Grinder
12in [305mm]
Manual Abrasive Saw
