Abrasive Blades for Sectioning

LONG LASTING BLADES FOR YOUR ABRASIVE CUTTERS

High Quality Sectioning

Blades for Abrasive Cutters

Achieve efficient cutting with extended lifetime and minimal surface deformation using Buehler’s performance-proven abrasive blades, ranging from 9″ [229mm] to 18″ [457mm]. Our full line of blades for abrasive cutters includes both rubber bonded and resin bonded blades for high quality cutting. If you have an orbital cutting machine or would like to cut more delicate samples, we also offer orbital and precision blades for your abrasive cutter.

Fast and Efficient

Choose Buehler’s large selection of blades for fast cutting and high quality sectioning results in your sample preperation process.

NEW Premium Resin Abrasive Blades

Buehler’s new abrasive blades provide extended lifetime so you can spend less time changing blades and lower your blades budget.

These new blades cut a full range of metallic materials and last up to 3 times longer than other abrasive blades in the market. You can rely on the consistency of the blades while the longevity leads to fewer blade changeovers.

Choosing Rubber Bonded vs. Resin Bonded Blades

While rubber bonded blades produce a great quality cut, they can emit a burnt odor while cutting. Resin bonded blades are a great alternative to reduce odor during cutting process while achieving a similar great performance.

Abrasive Blades

Buehler’s abrasive blades quickly section through samples, adding efficiency to your process. Buehler offers both rubber and resin abrasive blades to meet your sectioning needs.

AcuThin^® Blades

Choose our AcuThin series thin blades when you need a more precise cut with less surface damage and a thinner section of sample material removed. These rubber bond blades allow for delicate abrasive sectioning.

Orbital Blades

Our offering includes blades specialized for orbital cutters which also work well with other abrasive saws. These rubber bonded blades are available for ferrous and non-ferrous materials, superalloys, and more.

Diamond Blades

If traditional abrasive blades are not delicate enough for your needs, turn to our Diamond blade offerings for abrasive machines, especially when cutting very hard and brittle materials.

Abrasive Blades

Buehler’s abrasive blades quickly section through samples, adding efficiency to your process. Buehler offers both rubber and resin abrasive blades to meet your sectioning needs.

NEW Premium Resin Abrasive Blades

Buehler’s new abrasive blades provide extended lifetime so you can spend less time changing blades and lower your blades budget.

These new blades cut a full range of metallic materials and last up to 3 times longer than other abrasive blades in the market. You can rely on the consistency of the blades while the longevity leads to fewer blade changeovers.

Ordering

Abrasive Blades Selection, 1.25in [32mm] Arbor (Qty 10) [Blade Thickness is listed under Part Number]
Recommended Use	10in [254mm] Chop/Linear	12in [305mm] Chop/Linear	14in [356mm] Chop/Linear	16in [406mm] Chop/Linear
Superalloys, General Steel, Non-Ferrous	12-4205-010 0.051in [1.3mm]	12-4405-010 0.055in [1.4mm] 10-31205-010 0.08in [2.3mm]	12-4305-010 0.063in [1.6mm] 10-31405-010 0.10in [2.5mm]	10-31605-010 0.125in [3mm] 12-5605-010 0.075in [1.9mm]
Ferrous materials >HRC60	10-4210-010 0.083in [2.1mm] 102509P 0.06in [1.5mm]	12-4110-010 0.09in [2.3mm] 103009P 0.08in [2mm] 10-31218-010 0.08in [2mm]	10-4310-010 0.075in [1.9mm] 103509P 0.098in [2.5mm]	10-31610-010 0.125in [3mm]
Ferrous materials HRC50-60	10-4212-010 0.083in [2.1mm] 10-31014-010 0.06im [1.5mm]	10-4412-010 0.105in [2.7mm] 10-31212-010 0.08in [2mm]	10-4312-010 0.09in [2.3mm] 103509P 0.098in [2.5mm] 10-31412-010 0.10in [2.5mm]	10-31612-010 0.125in [3mm]
Ferrous materials HRC35-50	10-4216-010 0.083in [2.1mm] 102510P 0.06in [1.5mm] 10-31014-010 0.06in [1.5mm]	12-4116-010 0.105in [2.7mm] 103010P 0.08in [2mm] 10-31218-010 0.08in [2mm]	12-4305-010 0.063in [1.6mm] 103510P 0.098in [2.5mm] 10-31416-010 0.10in [2.5mm]	10-31616-010 0.125in [3mm]
Ferrous materials HRC15-35	10-4220-010 0.067in [1.7mm] 102511P 0.06in [1.5mm]	12-4120-010 0.105in [2.7mm] 103011P 0.079in [2mm]	12-4305-010 0.063in [1.6mm]
High Speed Steel, Stainless Steel, Carburized Steel	102508P 0.063in [1.6mm]	103008P 0.079in [2mm]	103508P 0.102in [2.6mm]
Delicate Cutting	10-4227-010 0.032in [0.8mm]
Titanium Alloys, Zirconium Alloys, Ductile Materials	10-4245-010 0.063in [1.6mm] 102507P 0.06in [1.5mm]	12-4145-010 0.087in [2.2mm] 103007P 0.079in [2mm]	10-4345-010 0.063in [1.6mm] 103507P 0.098in [2.5mm]
Non-Ferrous Materials (Aluminum, Copper, Brass), Very Soft Ferrous Materials	10-4250-010 0.063in [1.6mm] 102512P 0.06in [1.5mm]	103012P 0.079in [2mm]	10-4350-010 0.087in [2.2mm]	10-31650-010 0.125in [3mm]

Orbital Abrasive Blades Selection, 1.25in [32mm] Arbor (Qty 10) [Blade Thickness is listed under Part Number]
Recommended Use	12in [305mm] Orbital	14in [356mm] Orbital	16in [406mm] Orbital	18in [457mm] Orbital
Superalloys, General Steel, Non-Ferrous	12-4405-010 0.055in [1.4mm]	12-4305-010 0.063in [1.6mm]	12-5605-010 0.075in [1.9mm]	12-5805-010• 0.1in [2.5mm]
Ferrous materials >HR60	12-4410-010 0.105in [2.7mm]	12-4310-010 0.105in [2.7mm]	12-5610-010 0.125in [3mm]	12-5810-010 0.153in [3.8mm]
Ferrous materials HRC50-60	12-4410-010 0.105in [2.7mm]	12-4310-010 0.105in [2.7mm]	12-5612-010 0.125in [3mm]	12-5816-010 0.153in [3.8mm]
Ferrous materials HRC35-50	12-4416-010 0.105in [2.7mm]	12-4316-010 0.105in [2.7mm]	12-5616-010 0.125in [3mm]	12-5816-010 0.153in [3.8mm]
Ferrous materials HRC15-35	12-4420-010 0.105in [2.7mm]	12-4320-010 0.087in [2.2mm]	12-5616-010 0.125in [3mm]	12-5816-010 0.153in [3.8mm]
Titanium Alloys, Zirconium Alloys, Ductile materials			12-5645-010 0.075in [1.9mm]

AcuThin^® Blades (Qty 10) [Blade Thickness is listed under Part Number]
For certain applications, it is important to minimize the amount of damage done to the sample during sec- tioning. The AcuThin series offers thin blades that have been developed to minimize the area of cutting thus reducing the amount of damage to the sample. These blades utilize a rubber bond and allow for precise, delicate abrasive sectioning with minimal surface damage.
Recommended Use	9in [230mm]	10in [254mm]	12in [305mm] Chop	14in [356mm] Chop
General Use	102301 0.032in [0.8mm]	102501 0.04in [1mm]	10-4360-010 0.032in [0.8mm]	10-3501 0.063in [1.6mm]
Ferrous Materials >HRC45	10-4161-010 0.025in [0.635mm]	10-4261-010 0.025in [0.635mm]	10-4361-010 0.025in [0.635mm]	103502 0.105in [2.7mm]

Diamond Blades for Abrasive Cutters [Blade Thickness is listed under Part Number] 1.25in [32mm] Arbor (Qty 1)
Recommended Use	Blade Type	10in [250mm]	12in [300mm]	14in [350mm]
General Use	Diamond	114610E 0.051in [1.3mm]
Hard Materials	Diamond	114810E 0.047in [1.2mm]	103056 0.055in [1.4mm]	114814E 0.059in [1.5mm]
Ceramic and Petrographic samples	Diamond	114710E 0.047in [1.2mm]	103053 0.087in [2.2mm]	114714E 0.059in [1.5mm]
Plastics and Polymers	Diamond	102557 0.049in [1.25mm]

AbrasiMet L Pro Brochure

Frequently Asked Questions

What size abrasive blades do you recommend to use with the new AbrasiMet L?

The 12in and 14in premium abrasive blades are perfect to use with Buehler’s new AbrasiMet L.

What lubricant do you suggest to use along with abrasive blades?

Buehler Cool 3 Fluid is recommended for most applications.

What is HRC?

HRC (Hardness, Rockwell C) is a measure of difficulty in cutting, the higher this number the softer the blade bond.
